Harmonai AG12 12-Channel Professional Digital Mixer

The Harmonai AG12 is a 12-channel professional digital mixer featuring a 3rd-generation high-performance DSP processor, a 4.3-inch HD color capacitive touchscreen, six 100mm motori...

$351.76

Model: AG12
Category: Mixers
Images: 4 images
Status: ready

Product Brief

Harmonai AG12 12-Channel Professional Digital Mixer

Overview

The Harmonai AG12 is a 12-channel professional digital mixer featuring a 3rd-generation high-performance DSP processor, a 4.3-inch HD color capacitive touchscreen, six 100mm motori...

Price: $351.76
Model: AG12
Category: Mixers

Specifications

Parameter	Value
Input Channels	12 channels
Mic/Line Inputs	8 channels (XLR female + ¼" TRS)
Stereo Line-In	1 channel
USB Media Channel	1 channel (USB flash drive playback / Bluetooth audio / PC soundcard playback)
Output Channels	10 channels
AUX Outputs	4 channels
Main Output	Stereo Main L/R (XLR male, differential balanced output)
USB Recording	1 stereo USB recording / PC soundcard recording channel
Headphone Channel	1 stereo channel
Display	4.3-inch color TFT LCD screen, capacitive touchscreen
Motorized Faders	100mm travel × 6 units, 1024-step precision
DSP Processor	3rd-generation SIMD core, 300MHz/40-bit floating-point
Dynamic Range	114dB (typical)
Microphone Preamps	Professional high-dynamic-range, low-distortion preamps
Input Channel Processing	48V phantom power, polarity inversion, noise gate, compressor, 4-band parametric EQ, HPF, LPF
Output Channel Processing	Delay, 4-band parametric EQ, HPF, LPF, compressor (independently configurable)
DSP Effect Types	5 types (Echo / Reverb / Echo + Reverb / Flanger / Stereo Delay)
Effect Presets	Over 100
Effect Library	Supports customization and storage

Service Support

We support project consultation, model recommendation, bulk purchasing and catalog delivery for retail, multipurpose halls, conference rooms and live events.

Business hours: Monday to Friday 09:00 - 18:30
Inquiry channels: phone / email / website form
Tip: share budget, quantity and use scenario in advance

Product Overview

The Harmonai AG12 is a 12-channel professional digital mixer powered by a 3rd-generation high-performance DSP processor, delivering an 114dB typical dynamic range at 300MHz/40-bit floating-point precision. It features a 4.3-inch HD color TFT capacitive touchscreen and six 100mm motorized intelligent faders (1024-step resolution) for precise, fluid mixing control. Every input channel includes a premium microphone preamp with independent noise gate, compressor, 4-band parametric EQ, and high-pass/low-pass filters — meeting the rigorous demands of live performance, conferencing, and studio recording.

Input Channels

12 channels: 8 mic/line analog preprocessed inputs (XLR female + ¼" TRS), 1 stereo Line-In, and 1 stereo USB media channel (USB flash drive playback / Bluetooth audio / PC soundcard playback)

Output Channels

10 channels: 4 AUX outputs and 1 stereo Main L/R output (XLR male, differential balanced output circuit)

Recording & Headphones

1 stereo USB recording / PC soundcard recording channel; 1 stereo headphone channel

Display

4.3-inch high-definition color TFT LCD screen with capacitive touchscreen

Faders

100mm-travel motorized faders (6 total), motorized intelligent control, 1024-step precision

DSP Processor

3rd-generation high-performance digital signal processor (SIMD core), 300MHz/40-bit floating-point operation, 114dB typical dynamic range

Microphone Preamps

Premium-quality microphone/line preamps on all input channels — high dynamic range and low distortion

Input Channel Processing

48V phantom power, polarity inversion, noise gate, compressor, 4-band parametric EQ (PEQ), high-pass filter (HPF), low-pass filter (LPF)

Output Channel Processing

Delay, 4-band parametric EQ (PEQ), high-pass filter (HPF), low-pass filter (LPF), compressor — all independently configurable

DSP Effects

5 effect types: Echo, Reverb, Echo + Reverb, Flanger, Stereo Delay — over 100 effect presets; supports custom effect library creation and storage

Applications

The Harmonai AG12 is suited for small-to-medium live sound mixing, audio management in conference rooms and multi-purpose halls, multitrack mixing in streaming studios and recording studios, sound reinforcement in churches and banquet halls, and audio processing for education, training, and roadshow events. Its rich channel count, professional DSP processing, and intuitive touch control deliver reliable performance across diverse audio engineering applications.

Learn more about the Harmonai AG12 professional digital mixer, or contact our audio engineers for a customized solution consultation.
