MDX-22 22-Channel Digital Mixer — 4th-Gen Dual DSP, 16 Mic Inputs, Auto-Mix, 100+ Effects

The MDX-22 is a high-performance 22-channel digital mixer featuring 4th-generation dual DSP processing, 16 mic/line inputs + 2 stereo + 1 USB input, and comprehensive per-channel p...

$791.47

Model: MDX-22
Category: Mixers
Images: 4 images
Status: ready

Product Brief

MDX-22 22-Channel Digital Mixer — 4th-Gen Dual DSP, 16 Mic Inputs, Auto-Mix, 100+ Effects

Overview

The MDX-22 is a high-performance 22-channel digital mixer featuring 4th-generation dual DSP processing, 16 mic/line inputs + 2 stereo + 1 USB input, and comprehensive per-channel p...

Price: $791.47
Model: MDX-22
Category: Mixers

Specifications

Parameter	Value
Processor	4th-generation dual high-performance DSP digital signal processor (SIMD core)
DSP Effects	4 effect engines, 6 effect types, 100+ presets
Effect Types	Chorus / Echo / Flanger / Pitch Shift / Reverb / Stereo Delay
Input Channels	22 channels (16 mic/line + 2 stereo + 1 USB)
Output Channels	18 channels (8 AUX + 4 MTRX + stereo LR + USB recording + stereo monitor)
Input Processing	48V phantom power, polarity invert, noise gate, compressor, 4-band PEQ, high-shelf/low-shelf filters, HPF, LPF
Output Processing	Delay, GEQ, 4-band PEQ, high-shelf/low-shelf filters, HPF, LPF
DCA Groups	12 DCA volume groups
MUTE Groups	8 MUTE mute groups
Scene Shortcut Keys	6 keys, programmable for one-touch recall
Auto-Mix	Configurable on 8 AUX channels, with intelligent gain allocation and gain sharing algorithm
Private Label Customization	Supported; minimum order: 1 unit

Service Support

We support project consultation, model recommendation, bulk purchasing and catalog delivery for retail, multipurpose halls, conference rooms and live events.

Business hours: Monday to Friday 09:00 - 18:30
Inquiry channels: phone / email / website form
Tip: share budget, quantity and use scenario in advance

Product Overview

The MDX-22 is a high-performance 22-channel digital mixer, powered by a 4th-generation dual DSP processor (SIMD core), and equipped with 4 professional DSP effect engines and 6 effect types (Chorus, Echo, Flanger, Pitch Shift, Reverb, Stereo Delay), delivering over 100+ effect presets. It offers 22 inputs (16 mic/line + 2 stereo + 1 USB) and 18 outputs (8 AUX + 4 MTRX + stereo Main LR + USB stereo recording + stereo monitor). All mic/line input channels include 48V phantom power, noise gate, compressor, 4-band parametric EQ (PEQ), high-shelf/low-shelf filters, HPF, and LPF. 12 DCA groups and 8 MUTE groups streamline mixing workflows, while 6 scene shortcut keys enable one-touch recall.

Processor

4th-generation dual high-performance DSP digital signal processor (SIMD core)

DSP Effects

4 professional effect engines, 6 effect types, 100+ presets

Input Channels

22 channels: 16 mic/line + 2 stereo + 1 USB

Output Channels

18 channels: 8 AUX + 4 MTRX + 1 stereo LR + 1 USB recording + 1 stereo monitor

Input Processing

48V phantom power, polarity invert, noise gate, compressor, 4-band PEQ, high-shelf/low-shelf filters, HPF, LPF

Output Processing

Delay, GEQ, 4-band PEQ, high-shelf/low-shelf filters, HPF, LPF

DCA Groups

12 DCA volume groups

MUTE Groups

8 MUTE mute groups

Scene Shortcut Keys

6 keys, user-programmable for one-touch scene recall

Auto-Mix

Auto-mix configurable on all 8 AUX channels, with intelligent gain allocation algorithm

Private Label Customization

Supported; minimum order: 1 unit

Typical Applications

Leveraging its 4th-generation dual DSP architecture and 22 inputs, the MDX-22 excels in professional audio environments including large-scale concerts, theater productions, broadcast centers, conference rooms, and recording studios. Its auto-mix functionality and intelligent gain allocation algorithm are especially suited for multi-mic conference systems and panel discussions. The 12 DCA groups and 8 MUTE groups simplify complex mixing tasks, while the 6 scene shortcut keys allow rapid setup changes during live performances. USB stereo recording enables direct capture of live shows or meetings.
