Harmonai PA Professional Speaker Processor — All-in-One Digital Audio Management Solution

The Harmonai PA Professional Speaker Processor features a 24-bit A/D converter and dbx patented Type IV™ conversion circuit for >110dB dynamic range. It integrates stereo feedback...

$160.49

Model: PA
Category: Stage Accessories
Images: 4 images
Status: ready

Product Brief

Harmonai PA Professional Speaker Processor — All-in-One Digital Audio Management Solution

Overview

The Harmonai PA Professional Speaker Processor features a 24-bit A/D converter and dbx patented Type IV™ conversion circuit for >110dB dynamic range. It integrates stereo feedback...

Price: $160.49
Model: PA
Category: Stage Accessories

Specifications

Parameter	Value
Inputs & Outputs	2 inputs, 6 outputs
A/D Conversion	24-bit, dynamic range >110dB
Conversion Circuit	dbx patented Type IV™
Feedback Suppression	Stereo 2×12 fast-tracking notch filters
Graphic Equalization	Dual 28-band graphic equalizer
Compressor	Classic dbx compressor
Subharmonic Synthesis	120A subharmonic synthesizer
Crossover Configurations	Selectable 2×3 / 2×4 / 2×5 / 2×6
Parametric Equalization	Stereo multi-band parametric equalizer
Output Limiting	Stereo output limiters
Delay Adjustment	Loudspeaker fine-tuning delay
Room EQ Compensation	Auto-EQ automatic room EQ compensation
Preset Programs	25 factory presets + 25 user presets
Real-Time Analysis	RTA-M real-time spectrum analyzer
Microphone Input	Front-panel input with phantom power
Noise Generator	Pink noise generator
Setup Navigation	Setup Wizard, compatible with JBL loudspeakers and Crown amplifiers
Display	Graphical LCD display

Service Support

We support project consultation, model recommendation, bulk purchasing and catalog delivery for retail, multipurpose halls, conference rooms and live events.

Business hours: Monday to Friday 09:00 - 18:30
Inquiry channels: phone / email / website form
Tip: share budget, quantity and use scenario in advance

Harmonai PA Professional Speaker Processor product image

Product Overview

The Harmonai PA Professional Speaker Processor is an all-in-one digital audio processing device combining feedback suppression, equalization, compression/limiting, and crossover management. It employs a 24-bit A/D converter and dbx patented Type IV™ conversion circuit, delivering over 110dB of dynamic range to ensure signal purity and processing precision. Equipped with a graphical LCD display, it offers intuitive and convenient operation—making it an indispensable core processor for professional sound systems.

Inputs & Outputs

2 inputs, 6 outputs

A/D Conversion

24-bit, dynamic range >110dB

Conversion Circuit

dbx patented Type IV™

Feedback Suppression

Stereo 2×12 fast-tracking notch filters

Graphic Equalization

Dual 28-band

Compressor

Classic dbx compressor

Subharmonic Synthesis

120A subharmonic synthesizer

Crossover Configurations

Selectable: 2×3, 2×4, 2×5, or 2×6

Parametric Equalization

Stereo multi-band parametric EQ

Output Limiting

Stereo output limiters

Delay Adjustment

Loudspeaker fine-tuning delay

Room EQ Compensation

Auto-EQ automatic room EQ compensation

Preset Programs

25 factory presets + 25 user presets

Real-Time Analysis

RTA-M real-time spectrum analyzer

Microphone Input

Front-panel input with phantom power

Noise Generator

Pink noise generator

Setup Navigation

Setup Wizard (intelligent setup assistant), compatible with JBL loudspeakers and Crown amplifiers

Display

Graphical LCD display

Typical Applications

Ideal for professional stage performances, conference rooms, banquet halls, KTV rooms, Livehouses, theaters, and other medium-to-large-scale audio system installations. Its flexible 2-in/6-out architecture supports diverse loudspeaker configurations. Combined with Auto-EQ automatic room EQ compensation, it rapidly adapts to varying acoustic environments—ensuring optimal sound performance for every event.

For more product details or customized audio system solutions, contact us today for expert consultation.
