Harmonai GP-8600 Professional Dual-Channel True Diversity Wireless Microphone System

The Harmonai GP-8600 is a professional dual-channel true diversity UHF wireless microphone system with 160 selectable frequencies, 100-meter transmission range, dual-CPU control, P...

$149.12

Model: GP-8600
Category: Microphones
Images: 4 images
Status: ready

Product Brief

Harmonai GP-8600 Professional Dual-Channel True Diversity Wireless Microphone System

Overview

The Harmonai GP-8600 is a professional dual-channel true diversity UHF wireless microphone system with 160 selectable frequencies, 100-meter transmission range, dual-CPU control, P...

Price: $149.12
Model: GP-8600
Category: Microphones

Specifications

Parameter	Value
Product Type	Dual-channel true diversity wireless microphone system
Carrier Frequency Band	615–665 MHz
Modulation Method	FM (Frequency Modulation)
Oscillation Method	PLL phase-locked loop frequency synthesizer
Frequency Stability	±0.0005%
Selectable Frequencies	2 × 80 frequencies (160 total)
Receiver Bandwidth	40 MHz
Transmitter Bandwidth	80 MHz
Composite Signal-to-Noise Ratio	>108 dB
Composite Total Harmonic Distortion (T.H.D.)	<0.4% @ 1 kHz
Receiver Frequency Response	65 Hz–18 kHz ± 3 dB
Transmitter Frequency Response	50 Hz–18 kHz
Maximum Deviation	±45 kHz
Receiver Sensitivity	S/N > 60 dB at 25 kHz deviation / 6 dBμV input
Effective Transmission Range	100 meters (line-of-sight)
Balanced Output Voltage	−20 dBV/100 Ω
Unbalanced Output Voltage	−4 dBV/5 kΩ
Output Connectors	XLR balanced + 6.3 mm unbalanced
Transmitter Output Power	30 mW (standard 8 mW, optional 15 mW)
Maximum Input Sound Pressure Level (SPL)	130 dB SPL
Microphone Element Type	Handheld dynamic
Transmitter Power Source	2 × AA batteries
Transmitter Current Consumption	<150 mA
Harmonic Radiation	< −63 dBm

Service Support

We support project consultation, model recommendation, bulk purchasing and catalog delivery for retail, multipurpose halls, conference rooms and live events.

Business hours: Monday to Friday 09:00 - 18:30
Inquiry channels: phone / email / website form
Tip: share budget, quantity and use scenario in advance

Product Overview

Harmonai GP-8600 is a professional dual-channel true diversity wireless microphone system designed for stage performances. Featuring UHF (ultra-high-frequency) transmission, true diversity reception, dual-CPU control, PLL phase-locked loop frequency synthesis, large LCD display, and a rugged metal enclosure, it offers 160 selectable frequencies, intuitive operation, and exceptional signal stability. The entire unit is microcomputer CPU-controlled, enabling intelligent functions including frequency selection, display, mute locking, and battery level monitoring. It delivers an outstanding composite S/N ratio of up to 108 dB and a composite T.H.D. of less than 0.4%, meeting professional-grade audio performance requirements.

Carrier Frequency Band

615–665 MHz

Modulation Method

FM (Frequency Modulation)

Oscillation Method

PLL Phase-Locked Loop Frequency Synthesizer

Frequency Stability

±0.0005%

Selectable Frequencies

2 × 80 frequencies (160 total)

Composite Signal-to-Noise Ratio

>108 dB

Composite Total Harmonic Distortion (T.H.D.)

<0.4% @ 1 kHz

Frequency Response

65 Hz–18 kHz ± 3 dB

Maximum Deviation

±45 kHz

Effective Transmission Range

Up to 100 meters (line-of-sight)

Output Type

XLR balanced + 6.3 mm unbalanced

Maximum Output Voltage

Balance: −20 dBV/100 Ω; Unbalanced: −4 dBV/5 kΩ

Transmitter Output Power

30 mW (standard 8 mW, optional 15 mW)

Transmitter Frequency Response

50 Hz–18 kHz

Maximum Input Sound Pressure Level (SPL)

130 dB SPL

Microphone Element Type

Handheld dynamic

Transmitter Power Source

2 × AA batteries

Transmitter Current Consumption

<150 mA

Receiver Power Supply

DC 12 V–2 A / AC 100–240 V, 50/60 Hz

Harmonic Radiation

< −63 dBm

Certifications

CNAS/CMA test report, ISO 9001 Quality Management System, ISO 14001 Environmental Management System, ISO 45001 Occupational Health and Safety Management System, China Energy-Saving and Environmental Protection Product Certification, China Green Environmental Protection Product Certification

Recommended Applications

Thanks to its professional UHF wireless transmission, 160 selectable frequencies, and 100-meter effective range, the Harmonai GP-8600 is widely used in:Professional Stage Performances — ideal for duet or call-and-response singing, with independent dual channels operating without interference;Conference & Public Speaking — large LCD display and automatic clean-channel search ensure quick, hassle-free setup;KTV Entertainment Venues — dual balanced/unbalanced outputs connect seamlessly to mixers and KTV effects processors;Large-Scale Events & Wedding Performances — robust metal housing and handheld smart mute-locking deliver reliability and peace of mind. Backed by authoritative CNAS/CMA testing and multiple international quality certifications, this system guarantees consistent, high-performance audio.

For more information about the Harmonai GP-8600 professional wireless microphone system—or to request bulk pricing—please contact us anytime.
