Harmonai CM-610 Professional Cardioid Condenser Stage Microphone

The CM-610 is a professional condenser microphone designed for live stage performance. Its zinc alloy body and heat-treated grille ensure rugged durability, while its cardioid pola...

$8.07

Model: CML-610
Category: Microphones
Images: 4 images
Status: ready

Product Brief

Harmonai CM-610 Professional Cardioid Condenser Stage Microphone

Overview

The CM-610 is a professional condenser microphone designed for live stage performance. Its zinc alloy body and heat-treated grille ensure rugged durability, while its cardioid pola...

Price: $8.07
Model: CML-610
Category: Microphones

Specifications

Parameter	Value
Transducer Type	Back Electret Condenser
Polar Pattern	Cardioid
Frequency Response	70Hz–10kHz
Low-Frequency Roll-Off	180Hz, 12dB/oct
Sensitivity (48V)	-45dB ± 3dB (0dB = 1V/Pa @ 1kHz)
Sensitivity (1.5V Battery)	-46dB ± 3dB (0dB = 1V/Pa @ 1kHz)
Output Impedance (48V)	500Ω ± 20% (@ 1kHz)
Output Impedance (1.5V Battery)	600Ω ± 20% (@ 1kHz)
Maximum SPL (48V)	130dB (T.H.D ≤ 1% @ 1kHz)
Maximum SPL (1.5V Battery)	115dB (T.H.D ≤ 1% @ 1kHz)
Signal-to-Noise Ratio	70dB (1kHz @ 1Pa)
Dynamic Range (48V)	106dB (1kHz @ Max SPL)
Dynamic Range (1.5V Battery)	91dB (1kHz @ Max SPL)
Power Supply	48V DC phantom power / 1.5V AA battery, 2mA
Switch	ON/OFF latching reed switch
Weight	258g (without accessories)
Output Connector	XLRM 3-pin male (gold-plated)

Service Support

We support project consultation, model recommendation, bulk purchasing and catalog delivery for retail, multipurpose halls, conference rooms and live events.

Business hours: Monday to Friday 09:00 - 18:30
Inquiry channels: phone / email / website form
Tip: share budget, quantity and use scenario in advance

Harmonai CM-610 professional stage cardioid condenser microphone product image

Product Overview

The Harmonai CM-610 is a cardioid condenser microphone engineered specifically for professional stage performances. Featuring a zinc alloy body and heat-treated grille, it delivers robust, reliable construction built to withstand demanding live environments. The cardioid polar pattern precisely captures on-axis sound sources while effectively rejecting off-axis noise from the sides and rear. The latching reed switch prevents accidental power interruption during performance. The gold-plated XLR male connector ensures low-loss, high-quality audio signal transmission. It supports dual power options: 48V phantom power and 1.5V battery, offering flexible deployment across diverse scenarios.

Transducer Type

Back Electret Condenser

Polar Pattern

Cardioid

Frequency Response

70Hz – 10kHz

Low-Frequency Roll-Off

180Hz, 12dB/oct

Sensitivity (48V)

-45dB ± 3dB (0dB = 1V/Pa @ 1kHz)

Sensitivity (1.5V Battery)

-46dB ± 3dB (0dB = 1V/Pa @ 1kHz)

Output Impedance (48V)

500Ω ± 20% (@ 1kHz)

Output Impedance (1.5V Battery)

600Ω ± 20% (@ 1kHz)

Maximum SPL (48V)

130dB (T.H.D ≤ 1% @ 1kHz)

Maximum SPL (1.5V Battery)

115dB (T.H.D ≤ 1% @ 1kHz)

Signal-to-Noise Ratio

70dB (1kHz @ 1Pa)

Dynamic Range (48V)

106dB (1kHz @ Max SPL)

Dynamic Range (1.5V Battery)

91dB (1kHz @ Max SPL)

Power Supply

48V DC phantom power / 1.5V AA battery, 2mA

Switch

ON/OFF latching reed switch

Weight

258g (without accessories)

Output Connector

XLRM 3-pin male (gold-plated contacts)

Recommended Applications

The CM-610 microphone is ideal for all types of professional stage performances, including concerts, live band shows, theater productions, and music festivals. Its cardioid pattern enables precise vocal capture in noisy environments while minimizing interference from stage monitors and other sound sources. The latching reed switch ensures uninterrupted performance by preventing accidental shutdown due to unintended contact — making it a dependable choice for performers. With support for both phantom power and battery operation, it excels equally in wired studio recording and outdoor live events.

For detailed product information or bulk procurement solutions, contact our professional team for a customized quotation.
