Harmonai QY-JZ530 5×30W RGB Matrix Light for Bars & Live Streaming Studios

The Harmonai QY-JZ530 is a professional 5×30W RGB matrix effect light with independent pixel control per LED, DMX512/RDM support, and versatile lighting modes—including color wash,...

$83.54

Model: QY-JZ530
Category: Lighting Systems
Images: 4 images
Status: ready

Product Brief

Harmonai QY-JZ530 5×30W RGB Matrix Light for Bars & Live Streaming Studios

Overview

The Harmonai QY-JZ530 is a professional 5×30W RGB matrix effect light with independent pixel control per LED, DMX512/RDM support, and versatile lighting modes—including color wash,...

Price: $83.54
Model: QY-JZ530
Category: Lighting Systems

Specifications

Parameter	Value
Rated Voltage	AC 100–240V, 50/60Hz
Total Power Consumption	150W
LED Configuration	5 × 30W RGB LEDs
Control Modes	DMX512, Auto-run, Sound-activated, Master-slave, RDM, Pixel-level point control (each LED independently addressable)
DMX Channel Modes	CH03 / CH08 / CH15 / CH23
Dimming Precision	32-bit linear dimming, 0–100%
Effect Modes	Color wash, Strobe, Matrix (pixel-controlled)
Operating Temperature	−30°C to 80°C
Strobe Frequency	1–30Hz
Construction	Metal housing, black finish
Connectors	DMX512 In/Out, Power In/Out

Service Support

We support project consultation, model recommendation, bulk purchasing and catalog delivery for retail, multipurpose halls, conference rooms and live events.

Business hours: Monday to Friday 09:00 - 18:30
Inquiry channels: phone / email / website form
Tip: share budget, quantity and use scenario in advance

Harmonai QY-JZ530 5×30W RGB Matrix Light product image

Product Overview

The Harmonai QY-JZ530 is a professional 5×30W RGB matrix effect light designed specifically for entertainment venues such as bars, live streaming studios, and KTVs. It features five high-power 30W RGB LEDs—each individually controllable—to deliver diverse lighting effects including color wash, strobe, and matrix patterns, making it a single-light solution for multiple applications.

The fixture supports the DMX512 standard protocol and RDM remote management, offering multiple control modes: auto-run, sound-activated, master-slave, RDM, and pixel-level point control. Combined with 32-bit linear dimming technology, it ensures smooth, stepless brightness transitions from 0% to 100%. Its rugged black metal housing operates reliably across an extended temperature range of −30°C to 80°C, suitable for demanding environments.

Rated Voltage

AC 100–240V, 50/60Hz

Total Power Consumption

150W

LED Configuration

5 × 30W RGB LEDs

Control Modes

DMX512, Auto-run, Sound-activated, Master-slave, RDM, Pixel-level point control (each LED independently addressable)

DMX Channel Modes

CH03 / CH08 / CH15 / CH23

Dimming Precision

32-bit linear dimming, 0–100%

Effect Modes

Color wash, Strobe, Matrix (pixel-controlled)

Strobe Frequency

1–30Hz

Operating Temperature

−30°C to 80°C

Construction

Metal housing, black finish

Connectors

DMX512 In/Out, Power In/Out

Recommended Applications

Ideal for bar ambient lighting, live streaming studio backdrops, KTV room lighting design, small-stage performance setups, party and event atmosphere creation, and commercial display space illumination. Its flexible control options and rich effect library ensure seamless adaptation to diverse venue requirements.

For more product details or customized lighting solutions, contact the Harmonai Product Advisory Team.
